Images are illustrative and may not show every size or variation.
VOLT
Electric Actuated Economy Wafer Pattern Butterfly Valve
SKU EE5246
Sizes: 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100), 5" (DN125), 6" (DN150), 8" (DN200), 10" (DN250), 12" (DN300)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Economy Electric Actuated
- PN16 Wafer Pattern
- Epoxy Coated Cast Ductile Iron Body
- 316 Stainless Steel Disc and Shaft
- EPDM liner
- 10 Bar
- Sizes 2" to 12"
Description
An Economy Electric Actuated Wafer Pattern Butterfly Valve suitable for a range of applications including general purpose, water treatment, industrial and process plant. A great all round electrically operated, resilient seated, Wafer Pattern butterfly valve suitable to fit between PN10/16 flanges.
The valve has an Epoxy Coated Cast Ductile Iron Body, 316 Stainless Steel Disc and Shaft and EPDM liner, offering long service life and excellent value for money.
Available voltages: 24V DC, 24V AC, 110V AC and 230V AC.
Typical applications include:
Butterfly valves are maintenance free, economical and comply with 97/23/CE (PED) Directive CE 1115.
Electric Actuated Butterfly Valves are designed to meet the demanding needs of today's process flow control requirements. During build up all actuated packages are rigorously inspected and 100% factory tested prior to dispatch.
Technical specification
- Design
- Wafer
- Flange Accommodation
- PN16
- Body Material
- Ductile Iron
- Size
- 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100), 5" (DN125), 6" (DN150), 8" (DN200), 10" (DN250), 12" (DN300)
- Disc Material
- Stainless Steel 316L
- Liner
- EPDM
- Industry / Approvals
- HVAC
