VOLT
Economy Electric Actuated Stainless Steel 3 Piece Ball Valve
SKU EE5593
Sizes: 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Compact Electric Operated Ball Valve
- Stainless Steel Ball Valve
- Full Bore
- RPTFE Seats
- Screwed BSPT End Connections
- Sizes: 1/4" to 1"
- Working temperature range: -20°C to 200°C
- Maximum pressure rating: PN82
- HQ003 Electric Actuator
- Voltages: 24V DC, 110V AC, 230V AC
Description
This economy 3 piece stainless steel, full bore, ball valve is fitted with a compact and lightweight motorised actuator, offering reliability and extended operating life.
The valve features RPTFE (15%) seats, and PTFE seals and is available in sizes 1/4” (DN8), 3/8” (DN10), 1/2” (DN15), 3/4” (DN20),and 1” (DN25) with screwed BSPT end connections.
The actuator has an IP67 weatherproof aluminium housing and features 4 limit switches, anti-condensation heaters and a lever-operated manual override as standard. Available in operating voltages of 24V DC, 110V AC, and 230V AC and supplied with 3m of flying lead so removal of the cover is not required during installation.
Technical specification
- End Connection
- BSPT
- Body Material
- Stainless Steel
- Seat Material
- RPTFE
- Size
- 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25)
- Design
- 3 Piece
- Temperature Range
- -20°C to 200°C
- Pressure
- Maximum Working Pressure PN82
- Actuator
- HQ003 Electric Actuator
