Images are illustrative and may not show every size or variation.
VOLT
3 Way Sanitary Clamp End Direct Mount Ball Valve
SKU BV5102
Sizes: 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/2" (DN40), 2" (DN50), 3" (DN80)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- 3 Way Sanitary Clamp Ball Valve
- ASTM A351 CF8M 316 Stainless Steel Body
- 316 Trim
- Three way, L or T Port
- ISO 5211 Mounting Top for Easy Actuation
- Cavity Filled Ball Seats
- Virgin PTFE Seals
- BS4825 Clamp End Connections
- Sizes: 1/2" to 3"
- Full Bore Suitable for use on Pigged Pipework
Description
Our Stainless-Steel ball valve is a 3 Way sanitary valve with ISO 5211 direct mount top works and BS4825 Clamp End connections.
This valve is fully maintainable and particularly suited for on / off and diverting operation, in food processing, pharmaceutical and high velocity sanitary applications.
Classed as a high-performance valve it has the benefit of full bore up to 3”, with cavity filled PTFE seats and is supplied with a lockable lever handle.
Suitable for CIP / SIS in-line cleaning.
All sanitary valve components are cleaned and inspected to ensure they are free from contamination of grease, dust and additional hydrocarbon residues.
Stainless Steel Ball Valve 3 Way Hygienic Direct Mount Clamp End Datasheet
Technical specification
- End Connection
- Tri-Clamp
- Body Material
- Stainless Steel
- Seat Material
- Cavity Filled PTFE
- Size
- 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/2" (DN40), 2" (DN50), 3" (DN80)
- Design
- 3 Way, Full Bore
- Industry / Approvals
- Hygienic
- Lever
- Lockable Manual Lever
- Temperature Range
- See Chart
- Pressure
- Up to 1000 PSI/G
- Actuatable?
- Yes - ISO 5211 Mounting Pad with Square Drive
