VOLT
2 Piece Stainless Steel Economy Ball Valve - BSPP
SKU BV5574
Sizes: 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Economy 2 Piece Ball Valve
- Threads: BSPP
- CF8M Stainless Steel Body
- Full bore
- Sizes: 1/4" to 3"
- PTFE seats and seals
- Investment casting
- Blowout proof stem
Description
Our economy 2 piece stainless steel ball valve is a full bore ball valve, providing safe operation for both general, industrial, chemical and contaminated applications. It offers both economical and reliable operation expected from a non-maintainable ball valve.
CF8M Stainless Steel Body and PTFE seat. Used to 'shut-off' medium flows on a wide range of liquid and gaseous, it is supplied with a lockable lever grip insulated handle and is screwed BSPP.
Working Temperature: -20°C to +180°C
Maximum Working Pressure: 63 bar
Technical specification
- End Connection
- BSP, BSPP
- Body Material
- Stainless Steel
- Seal Material
- PTFE
- Seat Material
- PTFE
- Size
- 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80)
- Design
- 2 Piece, Female x Female
- Industry / Approvals
- General / Industrial / Process
- Lever
- Manual Lockable Lever
- Temperature Range
- -20°C to +180°C
- Pressure
- Up to: 63 bar Max Working Pressure
- Actuatable?
- No - Manual Only
