Images are illustrative and may not show every size or variation.
INOXPA
Inoxpa 6400 Hygienic CIP Ball Valve with Manual Locking Lever
SKU HB5304
Sizes: 1" (DN25), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Sanitary CIP Ball valve
- Manual Locking Lever
- Stainless steel AISI 316L
- Clamp or Weld End Connections
- EPDM Seal according to FDA 177.2600A
- Sizes: DN25 (1/2") to DN100 (4")
- Suitable for CIP / SIS in-line cleaning
Description
The Inoxpa 6400 Hygienic CIP Ball valve with Manual Locking Lever is a Stainless steel AISI 316L sanitary ball valve with clamp or weld end connections to ASME BPE. Suitable for manual on / off operation and fitted with a pad lockable pull lever handle. EPDM Seal (-10°C to +120°C) according to FDA 177.2600A and valve surface is hygienically polished in sizes: DN25 (1/2") to DN100 (4").
Compact and robust our sanitary ball valve, whether its manual or automatically actuated performs under most arduous duties giving low pressure losses and perfect isolation. Fitted generally in applications where an unobstructed flow is required. The valve is suitable for food processing, beverage, wine making, chemical, cosmetic and oil making.
Suitable for CIP / SIS in-line cleaning.
According to FDA 177.2600A.
Inoxpa 6400 Hygienic CIP Ball valve with Manual Locking Lever Datasheet
Technical specification
- End Connection
- Butt Weld OD, Tri-Clamp
- Body Material
- Stainless Steel 316L
- Seal Material
- EPDM (according to FDA 177.2600A)
- Size
- 1" (DN25), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100)
- Industry / Approvals
- Hygienic
- Lever
- Manual Locking Lever
- Temperature Range
- -10°C to +120°C
- Pressure
- Up to: 10 bar (DN 25 - 65 / DN 1" - 2 ½"), 8 bar (DN 80 - 100 / DN 3" - 4")
- Actuatable?
- On Request
