VOLT
Forged Steel Y Type Strainer Class 800
SKU YS5044
Sizes: 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/2" (DN40), 2" (DN50)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Y Type Strainer
- Forged Steel body
- Class 800
- 20 screen mesh
- BSPP, NPT or Socket Weld
- Sizes: 1/2" to 2"
- Temperature: -29°C to 425°C
- Pressure up to 138 bar
Description
Forged Steel Y Type Strainer Class 800 is used to protect expensive equipment installed in a pipeline from dirt, debris and particulates.
Supplied with a standard fine screen for effective filtration down to 20 mesh (920μm or 0.037”). Screwed Plug enables easy removal and cleaning of basket.
Available in forged steel and conforming to API 602 and ASME B16.34. Offered in various end connections for use with a wide range of applications including: - Steam, Thermal Oil, Air, Gas and water.
Can be fitted in horizontal and vertical downstream positions.
Typical applications:
Typical Industries:
Forged Steel Y Type Strainer Class 800 Datasheet
Technical specification
- End Connection
- BSP, NPT, Socket Weld
- Body Material
- Forged Steel
- Size
- 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/2" (DN40), 2" (DN50)
- Filtration
- 0.91mm (Mesh 20)
- Design
- Y Type
- Industry / Approvals
- Steam
