Cromax Stainless Steel Spring Check Valve Screwed BSP
SKU CV4673
Sizes: 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Mirror Finish Spring Check Valve
- 316 or 304 Stainless Steel body
- Viton seat
- Screwed BSP
- Sizes 1/4" to 2"
- Temperature: -20°C to 150°C
- Pressure rating: up to 16 Bar
Description
The Cromax Stainless Steel Spring Check Valve is screwed BSP and offers excellent sealing capabilities for both high and low pressures. The valve has a mirror finish which makes it ascetically pleasing for use in hygienic environments, general purpose water, industrial and HVAC. A reliable and robust non return valve with mirror polished 316 or 304 Stainless Steel body options and Viton seat.
Installed either vertically (upwards only) or horizontally.
For full details please download the accompanying datasheet.
Cromax Stainless Steel Spring Check Valve Screwed Datasheet
Technical specification
- End Connection
- BSP
- Design / Type
- Spring Check
- Industry / Approvals
- HVAC
- Body Material
- Stainless Steel, Stainless Steel 304, Stainless Steel 316
- Size
- 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50)
- Main Features
- 1/4" to 2" -20°C to 150°C Up to 16 Bar Rated
