Cast Steel Y Strainer ANSI Class 300
SKU YS5755
from£250.00ex VAT Not the right one? Identify your valve by photo
Sizes: 2" (DN50), 3" (DN80), 4" (DN100), 6" (DN150), 8" (DN200), 10" (DN250)
1
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
Description
ANSI 300 Cast Steel Strainer with stainless steel screen mesh. Easy to clean with a removable drain plug and bolted bonnet. All flange dimensions are as ASME B16.5.
Generally used to protect Valves and equipment from dirt and scale, which is often the cause of damage, energy loss and higher production costs.
Temperature up to 400°C.
Strainers have a large flow surface area which results in a minimal pressure drop.
Technical specification
- Body Material
- Cast Steel
- Size
- 2" (DN50), 3" (DN80), 4" (DN100), 6" (DN150), 8" (DN200), 10" (DN250)
- Filtration
- 0.38mm (Mesh 40)
- Design
- Y Type
- Industry / Approvals
- Steam
