Images are illustrative and may not show every size or variation.
VOLT
Bronze Flanged Gate Valve
SKU GV4204
from£112.22ex VAT Not the right one? Identify your valve by photo
Sizes: 1/2", 3/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
1
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Bronze Flanged Gate Valve
- Suitable for general purpose, industrial, marine and HVAC applications
- Bronze body with Metal seat
- End connection: Flanged PN6, PN10, PN16, ANSI 150 and Table D / E
- Sizes: 1/2" to 4"
- Temperature range: -20°C to 150°C
- Pressure rating: PN16
Description
Our Bronze Flanged Gate Valve is suitable for general purpose, industrial, marine and HVAC applications. A manual flanged valve with Bronze non-rising stem and body, Cast SG Iron Handwheel in PN6, PN10, PN16, ANSI 150, Table D and Table E.
Manufactured to BS5154.
Bronze Flanged Gate Valve Datasheet
Technical specification
- End Connection
- Flanged PN6, Flanged PN10, Flanged PN16, Flanged ANSI 150, Table E, Table D
- Body Material
- Bronze
- Size
- 1/2", 3/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
- Industry / Approvals
- HVAC, Marine
- Design
- Handwheel Non Rising Stem
- Main Features
- 1/2" to 4" Flanged PN6, PN10, PN16, ANSI 150, Table D / E -20°C to 150°C
