ANSI 150 Carbon Steel Parallel Slide Gate Valve

A range of parallel slide gate valves featuring a cast steel body, and forged steel disk. The valves have an external yoke, a rising stem and are operated by handwheel. Available in sizes 2”, 2 ½”, 3”, 4”, 5”, 6”, and 8”, with raised face flanged end connections to fit ANSI 150 flanges. The valves are designed in accordance with ASME B16.34 and manufactured as follows: Body/bonnet minimum wall thickness to ASME B16.34, flanged end dimensions to ASME B16.5, face-to-face dimensions to ASME B16.10, and pressure testing to ASME B16.34. Operating temperature range of -29˚C to 425˚C, and pressure rated ANSI Class 150.
