VOLT
All Stainless Steel Back Entry Process Pressure Gauge
SKU PG2015
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- All Stainless Steel Back Entry Process Pressure Gauge
- Stainless Steel case and bezel
- Plastic window
- AISI 316L Stainless Steel wetted parts
- Sizes: 40mm to 160mm, 1/8" to 1/2"
- -1 / 0 Bar up to 0 / 1000 Bar
Description
Our All Stainless Steel Back Entry Process Pressure Gauge forms part of our carefully selected range of gauges and accessories; typically used within the pharmaceutical, petrochemical and food and drink process industries. Features a Stainless Steel case and crimped bezel, polycarbonate window and AISI 316L Stainless Steel wetted parts. Bottom Entry connection also available.
In addition, both the 100mm and 160mm face gauges feature a micro-adjustable pointer, 30mm rear blow-out disc and Stainless steel removable flush bezel.
Suitable for gases, excluding oxygen or acetylene, up to a maximum of 25 Bar and the measurement of fluid liquids that are NOT : high viscous, high temperature (over 150°C), likely to crystallize / solidify or that are corrosive to copper or tin alloys.
All our Process Pressure Gauges are designed for applications and use according to European Standard EN837-1.
All Stainless Steel Back Entry Process Pressure Gauge Datasheet
Technical specification
- Type
- Pressure
- Design / Use
- All Stainless Steel
- Entry
- Back
- Face Diameter
- 40mm, 50mm, 63mm, 100mm, 160mm
- Range
- -1 / 0 Bar, 0 / 1 Bar, 0 / 2 Bar, 0 / 4 Bar, 0 / 7 Bar, 0 / 11 Bar, 0 / 14 Bar, 0 / 16 Bar, 0 / 20 Bar, 0 / 28 Bar, 0 / 40 Bar, 0 / 70 Bar, 0 / 100 Bar, 0 / 160 Bar, 0 / 200 Bar, 0 / 280 Bar, 0 / 400 Bar, 0 / 700 Bar, 0 / 1000 Bar
- Connection Size / Stem Length
- 1/8", 1/4", 3/8", 1/2"
- Case Material
- Stainless Steel
- Main Features
- 40mm to 160mm -1 / 0 Bar up to 0 / 1000 Bar Back Entry
