Images are illustrative and may not show every size or variation.
VOLT
Stainless Steel Pressure Sustaining Valve - Flanged PN16
SKU PR4514
Sizes: 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100), 6" (DN150)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Pressure Sustaining Valve
- Direct Acting
- Stainless Steel Body
- Gauge Included
- NBR or Viton Seals
- DN15 to DN150 (1/2" to 6")
- Flanged PN16
- Adjustment Pressure: 1-5 Bar & 4-10 Bar
- Temperature: -15°C to 80°C
Description
The PR4514 is a stainless steel flanged (PN16) pressure sustaining valve that’s direct acting and available in sizes from DN15 to DN150 (1/2" to 6").
Available in two adjustment ranges of 1-5 bar and 4-10 bar.
The maximum inlet pressure is 25 bar (test pressure 35 bar). The valve is suitable for air, water light oil and other flowing media, that has a viscosity of less than 40 centipoise.
Sustaining or back pressure valves are designed to maintain a pre-set back pressure in a system (inlet or upstream pressure). The valve ensures pressure does not fall below the set range and therefore maintains critical systems upstream.
Stainless Steel Pressure Sustaining Valve - Flanged PN16 Datasheet
Technical specification
- Adjustment Range
- 1 - 5 bar, 4 - 10 bar
- Body Material
- Stainless Steel
- End Connection
- Flanged PN16
- Size
- 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40), 2" (DN50), 2 1/2" (DN65), 3" (DN80), 4" (DN100), 6" (DN150)
- Main Features
- NBR or Viton Seals DN15 to DN150 (1/2" to 6") Flanged PN16 1-5 Bar & 4-10 Bar
