Stainless Steel Pressure Sustaining Valve - BSP
SKU PR4513
Sizes: 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/2" (DN40), 2" (DN50)
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Pressure Sustaining Valve
- Direct Acting
- Stainless Steel Body
- Gauge Included
- NBR or Viton Seals
- 1/2" to 2"
- Screwed BSP
- Adjustment Pressure: 1-5 Bar & 4-10 Bar
- Temperature: -15°C to 80°C
Description
The PR4513 is a BSP screwed all stainless steel pressure sustaining valve that’s direct acting and available in sizes from1/2" to 22.
Available in two adjustment ranges of 1-5 bar and 4-10 bar.
The maximum inlet pressure is 25 bar (test pressure 35 bar). The valve is suitable for air, water light oil and other flowing media, that has a viscosity of less than 40 centipoise.
Sustaining or back pressure valves are designed to maintain a pre set back pressure in a system (inlet or upstream pressure). The valve ensures pressure does not fall below the set range and therefore maintains critical systems upstream.
Stainless Steel Pressure Sustaining Valve - BSP Datasheet
Technical specification
- Adjustment Range
- 1 - 5 bar, 4 - 10 bar
- Body Material
- Stainless Steel
- End Connection
- BSP
- Size
- 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1 1/2" (DN40), 2" (DN50)
- Main Features
- NBR or Viton Seals 1/2" to 2" BSP 1-5 Bar & 4-10 Bar
