Gemu
Gemu Variable Area Flow Meter for Air
SKU GE0805
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- Variable Area Flow Meter for Air
- Tube material: Trogamid-T (PA)
- Float material: PA
- Union End with DIN Insert (Socket)
- Sizes: DN10 - DN65
- Operating temperature: 20°C up to 120°C
Description
Gemu's Variable Area Flow Meter for Air provides a good level of accuracy, is simple to use and operates on the variable area principle. Available in short or long pattern, sizes: DN10-DN25 (0.02-0.36 up to 1.0-20.0 Nm3/hr) and DN20 to DN65 (0.2-2.5 up to 20.0-200.0 Nm3/hr).
The VA flow meter (rotameter) provides a clear, visual indication of the working medium and should be installed in a vertical pipe, with the working medium flowing from bottom to top. The float moves freely in the conical tube, lifted by the flow of the media allowing readings to be taken from the visual scale.
Monitoring and signal sensing can also be achieved with the addition of limit switches mounted the flow meter.
