Images are illustrative and may not show every size or variation.
Gemu
GEMU 677 PVC-U Diaphragm Valve
SKU GER677
Sizes: DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100
Checking online availability…
- Next-day UK delivery on stock items
- Trade and bulk pricing available on request
- PVC-U body
- EPDM or EPDM / PTFE diaphragm seal
- Standard or locking handwheel
- DIN spigot or, Union End with either DIN Weld or BS Weld sockets
- Sizes: DN15 - DN100
- Suitable for inert and corrosive* liquid and gaseous media
Description
GEMU 677 PVC-U Diaphragm Valve is insensitive to particulate media, suitable for inert and corrosive* liquid and gaseous media. A 2/2 way valve benefiting from a compact, weight saving design and minimal or low-maintenance plastic bonnet with ergonomically designed handwheel.
Body and diaphragm sizes have co-ordinated diameter’s which help to reduce the fitting time, due to the fact that the pipe and fixing centres remain the same.
All medium wetted parts, the handwheel and bonnet of the Gemu 677 Diaphragm Valve are made of plastic.
* Please download the accompanying technical datasheet for further information.
Technical specification
- Body Material
- PVC-U
- Diaphragm Material
- EPDM, PTFE / EPDM
- End Connection
- Spigot, Union Ends with DIN Weld Socket, Union Ends with BS Weld Socket
- Size
- DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100
- Main Features
- DIN Spigot or Union End with DIN Weld or BS Weld Sockets EPDM or EPDM/PTFE Diaphragm DN15 to DN100
